Language:
Epson ESC/P Raster, Epson ESC/P 2, IBM 24E Speed: Black Text 8PPM, Color 7PPM Internal Buffer: 32KB Graphics: up to 1440x720dpi Color InkJet Technology |
Bitmap Fonts
Epson Courier, Epson Prestige, Epson Script. Available in 10, 12, and 15 cpi.
Scalable Fonts
Epson Roman, Epson San Serif, Epson Roman T, Epson San Serif H. Available from 8-32 points in 2 point increments. Normal, bold, italic, and bold italic.
Unprintable Region
Top: .12"
Bottom: .12"
Left: .12"
Right: .12"
Continuous Feeding
Standard Feeder: Input Tray 100 sheets or 10 envelopes. Output Tray 30 sheets.
Paper | Size | Paper Types | Thickness | Weight |
Single Sheets | Letter, A4, A5, B5, Legal, Half letter, Executive | Plain paper and special ink jet papers from Epson. | .003 to .004 inch | 17 to 24 lb. |
Transparencies and glossy media | Letter, A4, A6 glossy film only | Transparencies, glossy paper, and glossy film from Epson | Glossy film and transparencies .0051 to .0059 inch. Glossy paper .0067 to .0071 inch. | |
Self adhesive sheets | A4 | Self adhesive sheets from Epson | ||
Envelopes | No 10, DL, C6 | Plain, bond or air mail paper | .006 to .017 inch | 12 to 20 lb. |
Cards | A6, 5 x 8, 8 x 10 | Ink jet cards from Epson | .0091 inch | 50.7 lb |
Loading Envelopes
Front Panel
Power Light | The Printer is on. |
Power Light Flash | Receiving Data, Replace ink cartridge, cleaning heads, certain error conditions. |
Paper Out Light | Paper is out, or there is a paper jam. |
Load/Eject button | Loads or ejects a sheet of paper if you press and release it within two seconds. Hold the Load/Eject button while turning the printer on will run a printer check. |
Ink Light Flash | Ink is low. |
Ink Light On | Replace inc cartridge. |
Ink Buttons | Clean print heads, replacing ink cartridges. |
Parallel
Availability: Standard
Connection: Centronics Female
Activation: Default
Serial
Availability: Optional
LocalTalk
Availability: Optional
Ethernet, Coax, Twinax
Availability: Optional
