DeskJet 1000Cxi /1000Cse

dj1000c.gif (20625 bytes) Language: Printer Performance Architecture

Speed: 6ppm black and white, 3.5ppm color

Memory: 512 KB max.

Graphics: 600dpi

 FontsPaperInterfaces

Hewlett-Packard DeskJet 1000C Fonts

This printer has no internal fonts.

Hewlett-Packard DeskJet 1000c Paper Handling

Continuous Feeding

Standard Tray:

Loading the Standard Tray:

  1. Raise the output ray and extend the paper width and length adjusters to the maximum.
  2. Insert up to a maximum of 150 sheets of paper aligning the right edge of the paper stack against the right side of the tray, print side down.
  3. Slide the paper width and length adjusters in until they press lightly against the paper stack.
  4. Lower the output tray to its horizontal position.

Manual Feeding:

Loading the Top Media Feed:

  1. Extend the paper width and length adjusters to the maximum.
  2. Insert up to a maximum of 150 sheets of paper aligning the right edge of the paper stack against the right side of the tray, print side down.
  3. Slide the paper width and length adjusters in until they press lightly against the paper stack.
  4. Set the paper size in the printer driver dialog box.

Envelopes:

  1. Make sure all paper is removed from the top media feed.
  2. Insert up to 3 envelopes against the right side of the tray, with the flaps up and print side down.
  3. Slide the paper width adjuster in until it presses lightly against the envelopes.
  4. Push the tabs near the paper output slot down until they lock in place.
  5. In HP's print settings dialog box, click the SETUP tab and select the correct size of the envelope in the paper size box. DO NOT set to manual feed.

Labels:

  1. Make sure non of the pages are sticking together.
  2. Slide the stack of labels against the right side of the tray, print side down.
  3. Slide the width and length adjusters in until they press lightly against the labels.
  4. In HP's print settings dialog box, click the "setup" tab and select "In-Tray" in the Paper Source box.

Media Specifications:

General Type Sizes (mm) Sizes (inch)
Hagaki Card (minimum size) 100 x 148 3.94 x 5.83
4 x 6 Index Card 101.6 x 152.4 4 x 6
A6 Card 105 x 148.5 4.13 x 5.85
5 x 8 Index Card 127 x 203.2 5 x 8
Statement 139.7 x 215.9 5.5 x 8.5
A5 148.5 x 210 5.85 x 8.27
DL Envelope 210 x 110 8.27 x 4.33
No. 10 Envelope 104.65 x 241.3 4.12 x 9.5
C6 Envelope 114 x 152 4.49 x 5.98
B5 182 x 257 7.16 x 10.12
Executive 184.15 x 260.35 7.25 x10.25
Letter 215.9 x 279.4 8.5 x 11
A4 210 x 297 8.27 x 11.69
Legal 215.9 x 355.6 8.5 x 14
B4 257 x 364 10.12 x 14.33
Tabloid 279.4 x 431.8 11 x 17
A3 297 x 420 11.69 x 16.54
Super B (maximum size) 330.2 x 482.6 13 x 19

Hewlett-Packard DeskJet 1000c Messages


The lights on the front of the printer indicate whether the printer is off or on, in the process of receiving data or printing, or in an error state. The following table describes how the lights appear during printing.

Condition Cause
All lights are off. The printer is off.
The Power Light is on. The printer is ready to print. You can send a document to the printer.
The Power Light is blinking. The printer is receiving data from the computer or is printing. Wait for the document to print.
The Print Cartridge Light is blinking. The access door is open, no print cartridge is installed, a print cartridge has failed, the tape on the cartridges has not been removed, or the electrical contacts are dirty.

The following conditions will be indicated by the LEDs on the front panel. Not all of these conditions are errors and the blinking sequence is not necessarily unique for each case.

Power Resume Cartridge Possible
LED LED LED Causes User Actions

On Blinks Off Out of Paper Load more paper and press the Resume button.
On Blinks Off Paper Jam Clear the paper jam.
On Blinks Off Form Feed State Eject the paper by pressing the Resume button.
On Blinks Off Out of Paper Sensor is stuck Make sure the Out of Paper Sensor is not damaged or obstructed. The sensor is a black L-shaped piece of plastic located behind the silver rod the ink cartridge carriage slides on. The tip of the sensor is located between the two right paper feed rollers inside the printer.
On Blinks Off Waiting for media in the manual feed Load media in the manual feed in the back of the printer.
On Off Blinks Missing ink cartridge Both print cartridges must be installed in the printer carriage.
On Off Blinks Ink cartridge is not detected * Remove both ink cartridges and reinsert them.
* Make sure the blue or green tape has been removed from ink cartridge.

* Clean the electrical contacts on the ink cartridge and carriage with a lint-free cotton cloth slightly dampened with water. (The printer should be off when cleaning the carriage contacts.)

* Replace the ink cartridge.

Blinks Blinks Off Carriage Stall Clear the carriage stall by removing any objects that may be obstructing the ink cartridge carriage.
Blinks Blinks Blinks Printer Error Turn the printer off and unplug the power cord for a few seconds.

Hewlett-Packard DeskJet 1000C Interfaces

Centronics only.
